| Place of Origin: | GUANGDONG,CHINA |
|---|---|
| Brand Name: | JINYU |
| Certification: | SGS,CE |
| Model Number: | JY-350XD |
| Minimum Order Quantity: | 1 set |
| Price: | Negotiated |
| Packaging Details: | Plastic film+wooden case, about 3-8cbm |
| Delivery Time: | 15 to 20 work days |
| Payment Terms: | T/T, Western Union,Cash |
| Supply Ability: | 100 sets per month |
| Product Name: | Full Automatic Hardware Metal Tube Packing Machine In Good Performance | Function: | Servo Motor Control, Easy Operation |
|---|---|---|---|
| Material: | 304 Stainless Steel | Packing Speed: | 20-80bags/min |
| Bag Width: | 50mm-160mm | Bag Length: | 100mm-longer |
| Delivery Time: | Within One Week | Advantage: | Mature Production Experience With Over 13 Years |
| High Light: | tube packing machine,flow wrap packaging machine |
||
Full Automatic Hardware Metal Tube Packing Machine in Good Performance
Feature:
1.3 Servo motors , PLC controller , flexible bag length setting and cutting , saving time film.
2.Touchable human –machine operation , convenient and quick parameter setting.
3.Self diagnosis failure function , clear failure display.
4.High sensitivity optical electrical color mark tracking and digital input cut position which makes the sealing and cutting more accurate.
5.Separete PID control to temperature , suitable for various packing materials.
6.Stopping the machine in selected position , no , sticking to the knife and no waste packing film.
7.Simple driving system , reliable working , convenient maintenance.
8.All the controls is are achieved by software , convenient for function adjusting and upgrading.
9.Automatic sense material length , automatic packaging products , no product no packaging , don’t need to adjust the bag length.
10.High precision auto card feeder, zero error card issuing function, touch screen simple settings, leaflets or multiple can be.
11.Screws auto counting, auto feeding, auto packing, lack of material automatic alarm function!
Optional device:
1.Date coder 2.Automatic punching Device 3.Full Stainless 4.Large Touch Screen 5.Air filling device 6.Release the air 7.No empty bag function 8.Customized sealing patterns and notch 9.Automatic feeder 10. Automatic feeding device
Parameter:
| Model | JY-350XD | JY-450XD | JY-600XD | JY-700XD |
| Film width | Max. 350mm | 450mm | 600mm | 700mm |
| Bag length | 100~400mm | 100-450mm | 120-500mm | 120-500mm |
| Bag width | 50~160mm | 50-180mm | 100-280mm | 100-330mm |
| Product height | Max. 60mm | max.80mm | max.80mm | max.80mm |
| Film roll diameter | Max. 320mm | |||
| Packing speed | 10~80bag/min | 30-150bags/min | 30-150bags/min | 30-150bags/min |
| Powder | 220V,50/60Hz,2.8KW | 220V 50/60HZ 2.8KW | 220V 50/60HZ 2.8KW | 220V 50/60HZ 2.8KW |
| Dimension | 4020×720×1320mm | 4020x820x1450mm | 4020x920x1460mmm | 4020x980x1480mm |
| Machine weight | 550Kg | 580kg | 610kg | 680kg |
1. Free consultation service before, during, and after sales;
2. Free project planning and design services;
3. Free debugging of equipment until everything is functional;
4. Free management of equipments' long distance shipping;
5. Free training of equipment maintenance and operating personally;
6. Free new production techniques and formulas;
7. Provide 1 year complete warrantee and lifetime maintenance service.
